Engineering Deliverables / Portfolio Showcase
Live Plant Engineering Projects
At Deep Ocean, engineering training is practical and workflow-driven. Every diploma graduate completes live industrial plant capstones that simulate real EPC project deliverables.
CAP-01
Piping & Layout Engineering
Offshore Wellhead Platform Topside Piping
Students model a multi-deck offshore production module conforming to API RP 14E and ASME B31.3. Includes equipment layout, line routing, stress analysis, and 120+ isometric extractions.
Software Stack:
AVEVA E3DCAESAR IINavisworks
Assessed Deliverables:
- 3D E3D Model & Clash Matrix
- Stress Calculation Dossier
- Extraction of 120+ Fabrication ISOs
- Material Takeoff (MTO)
CAP-02
Refining & Petrochemical
Crude Oil Distillation Unit (CDU) Piping Train
Execution of a high-temperature crude preheat train, fractionating column piping, and reboiler loops with thermal expansion flexibility and spring support design.
Software Stack:
Intergraph SP3DCAESAR IIAutoCAD P&ID
Assessed Deliverables:
- SP3D Intelligent Piping Model
- ASME B31.3 Stress Reports
- Nozzle Load Verification
- Piping General Arrangement Drawings
CAP-03
Gas Processing & Treatment
Gas Sweetening & Amine Regeneration Unit
Design of sour gas processing skid units, column external piping, pump manifold configurations, and maintenance access clearance studies.
Software Stack:
AutoCAD Plant 3DCAESAR II
Assessed Deliverables:
- Plant 3D Complete Model
- Equipment Nozzle Schedules
- Tie-In Point Documentation
- Orthographic Section Drawings
