Compressed Air System Package for KKNPP 3&4 & Plant 3D Piping

Project Scope

Providing PDMS 3D modeling of Compressed Air System Package for KKNPP 3&4 Project in Aveva PDMS suite. Providing AutoCAD Plant3D for Trestle Area Piping, Compressed piping, Tank Farm Area Piping, and Utility building piping. PDMS equipment modeling (pumps, valves, tanks, skid packages, Local Control Panels). Pipe routing and pipe supports modeling. Civil structure modeling (RCC, steel structure, platforms & ladders). Electrical and instrumentation cable tray/trench modeling, pipe racks, interconnecting piping up to terminal point, PDMS clash check, and AutoCAD Plant3D 3D modeling, drafting, isometric extraction, and support extraction.

Project Highlights

• •Executed critical nuclear power plant balance package in AVEVA PDMS suite for KKNPP 3&4
• •Multi-area Plant3D coverage: Trestle Area, Tank Farm Area, Utility Building, and Compressed Piping
• •Detailed civil/structural modeling including RCC structures, steel frames, platforms, and ladders
• •Integrated electrical/instrumentation cable trench and tray routing with interconnecting pipe racks
• •Zero hard clashes verified via comprehensive PDMS clash detection audits
